Features
- suitable for Indoor applications
- inbuilt electronic controller with colour display
- protection class IP 54
Quick Links
Heat exchanger performance 7 W/K Operating Temperature Range -5°C - 55°C Air flow volume (system / unimpeded) Ambient air circuit: 76 / 300 m³/h
Cabinet air circuit: 87 / 300 m³/hMounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
508 x 196.5 x 152 mm Weight 7.5 kg Voltage / Frequency 230 V ~ 50/60 Hz UL Voltage / Frequency 230 V ~ 60 Hz Starting current 1.3 A Max. current 0.6 A Max. power 65 W Fuse 1 A (T) Connection 8 - pin Connector Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 58007002 Box dimension 560 x 274 x 206 mm Gross weight 9.5 kg Taric code 84158300 GTIN (EAN) 5350604200005
Heat exchanger performance 7 W/K Operating Temperature Range -5°C - 55°C Air flow volume (system / unimpeded) Ambient air circuit: 76 / 300 m³/h
Cabinet air circuit: 87 / 300 m³/hMounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
508 x 196.5 x 152 mm Weight 7.5 kg Voltage / Frequency 120 V ~ 60 Hz UL Voltage / Frequency 120 V ~ 60 Hz Starting current 1.3 A Max. current 1.1 A Max. power 65 W Fuse 1.6 A (T) Connection 8 - pin Connector Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 58007102 Box dimension 560 x 274 x 206 mm Gross weight 9.5 kg Taric code 84158300 GTIN (EAN) 5350604200012
