Features
- suitable for Indoor applications
- inbuilt electronic controller with colour display
- protection class IP 54
Quick Links
Heat exchanger performance 43 W/K Operating Temperature Range -5°C - 55°C Air flow volume (system / unimpeded) Ambient air circuit: 310 / 850 m³/h
Cabinet air circuit: 310 / 850 m³/hMounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
1,194 x 254 x 151.3 mm Weight 16.7 kg Voltage / Frequency 230 V ~ 50/60 Hz UL Voltage / Frequency 230 V ~ 60 Hz Starting current 2 A Max. current 0.9 A Max. power 195 W Fuse 1.6 A (T) Connection 8 pin connector Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 58043002 Box dimension 1241 x 338 x 216 mm Gross weight 20 kg Taric code 84195000 GTIN (EAN) 5350604200098
Heat exchanger performance 43 W/K Operating Temperature Range -5°C - 55°C Air flow volume (system / unimpeded) Ambient air circuit: 310 / 850 m³/h
Cabinet air circuit: 310 / 850 m³/hMounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
1,194 x 254 x 151.3 mm Weight 16.7 kg Voltage / Frequency 120 V ~ 60 Hz UL Voltage / Frequency 120 V ~ 60 Hz Starting current 2.2 A Max. current 1.8 A Max. power 195 W Fuse 3 A (T) Connection 8 pin connector Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 58043102 Box dimension 1241 x 338 x 216 mm Gross weight 20 kg Taric code 84195000 GTIN (EAN) 5350604200104
