Features
- suitable for Indoor applications
- inbuilt electronic controller with colour display
- protection class IP 54
Quick Links
Heat exchanger performance 32 W/K Operating Temperature Range -5°C - 55°C Air flow volume (system / unimpeded) Ambient air circuit: 250 / 550 m³/h
Cabinet air circuit: 255 / 550 m³/hMounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
750 x 254 x 151 mm Weight 12 kg Voltage / Frequency 230 V ~ 50/60 Hz UL Voltage / Frequency 230 V ~ 60 Hz Starting current 1.6 A Max. current 0.6 A Max. power 150 W Fuse 1 A (T) Connection 8 pin connector Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 58032002 Box dimension 852 x 279 x 202.5 mm Gross weight 15 kg Taric code 84158300 GTIN (EAN) 5350604200067
Heat exchanger performance 32 W/K Operating Temperature Range -5°C - 55°C Air flow volume (system / unimpeded) Ambient air circuit: 250 / 550 m³/h
Cabinet air circuit: 255 / 550 m³/hMounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
750 x 254 x 151 mm Weight 12 kg Voltage / Frequency 120 V ~ 60 Hz UL Voltage / Frequency 120 V ~ 60 Hz Starting current 1.6 A Max. current 1.4 A Max. power 150 W Fuse 3 A (T) Connection 8 pin connector Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Stainless steel housing part no. 58032102 Box dimension 852 x 279 x 202.5 mm Gross weight 15 kg Taric code 84158300 GTIN (EAN) 5350604200074
