Features
- suitable for stainless steel enclosures and control panels
- for indoor and outdoor applications
- maintenance free
- can be mounted in any position
(depending on the installation the condensate management may need to be adjusted)
Order Number 6405303 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress Protection IP 66 / UL Type 12, 4, 4X Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Accessories Condensate Kit 6405 Cooling capacity L35L35 400 W Operating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Air flow volume (system / unimpeded) Ambient air circuit: 240 / 325 m³/h
Cabinet air circuit: 240 / 325 m³/hMounting Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
600 x 432 x 199 (135+64) mm Weight 34 Kg Cut out dimensions 382 x 550 mm Voltage / Frequency 120 V, 230 V Current L35L35 4.1 A @ 120 V
2.1 A @ 230 VStarting current 6.5 A @ 120 V
3.4 A @ 230 VMax. current 4.5 A @ 120 V
2.3 A @ 230 VNominal power L35L35 490 W Max. power 537 W Fuse 7 A (T) @ 120 V
4 A (T) @ 230 VConnection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files 2D - PDF Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 64053034 Box dimension 686.6 x 454 x 232 mm Gross weight 38 kg Taric code 84158300
