Features
- suitable for stainless steel enclosures and control panels
- for indoor and outdoor applications
- maintenance free
- can be mounted in any position
(depending on the installation the condensate management may need to be adjusted)
Order Number 6805323 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress Protection IP 66 / UL Type 12, 4, 4X Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Accessories Condensate Kit 6805 Cooling capacity L35L35 (EN14511-3) 800 W Operating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Air flow volume (system / unimpeded) Ambient air circuit: 480 / 650 m³/h
Cabinet air circuit: 480 / 650 m³/hMounting Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
975 x 517 x 202 (134+68) mm Weight 66 kg Cut out dimensions 464 x 922 mm Voltage / Frequency 230 V ~ 50/60 Hz Current L35L35 4.3 A Starting current 8 A Max. current 4.7 A Nominal power L35L35 979 W Max. power 1078 W Fuse 7 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 68053234 Box dimension 1060 x 612 x 260 mm Gross weight 75.5 kg Taric code 84158300
Order Number 6805313 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress Protection IP 66 / UL Type 12, 4, 4X Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Accessories Condensate Kit 6805 Cooling capacity L35L35 (EN14511-3) 800 W Operating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Air flow volume (system / unimpeded) Ambient air circuit: 480 / 650 m³/h
Cabinet air circuit: 480 / 650 m³/hMounting Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
975 x 517 x 202 (134+68) mm Weight 66 kg Cut out dimensions 464 x 922 mm Voltage / Frequency 120V ~ 60 Hz Current L35L35 8.2 A Starting current 14 A Max. current 9 A Nominal power L35L35 979 W Max. power 1078 W Fuse 13 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 68053134 Box dimension 1060 x 612 x 260 mm Gross weight 75.5 kg Taric code 84158300
Order Number 6805325 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress Protection IP 66 / UL Type 12, 4, 4X Included Condensate drain socket Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Cooling capacity L35L35 (EN14511-3) 800 W Operating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Air flow volume (system / unimpeded) Ambient air circuit: 480 / 650 m³/h
Cabinet air circuit: 480 / 650 m³/hMounting Wall mounted (with frame) Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
975 x 517 x 205 mm Weight 70 kg Cut out dimensions 464 x 922 mm Voltage / Frequency 230 V ~ 50/60 Hz Current L35L35 4.3 A Starting current 8 A Max. current 4.7 A Nominal power L35L35 979 W Max. power 1078 W Fuse 7 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 68053254 Box dimension 1060 x 612 x 260 mm Gross weight 79.5 kg Taric code 84158300
Order Number 6805315 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress Protection IP 66 / UL Type 12, 4, 4X Included Condensate drain socket Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Cooling capacity L35L35 (EN14511-3) 800 W Operating Temperature Range -20°C - 70°C UL temperature range -20°C - 65°C Air flow volume (system / unimpeded) Ambient air circuit: 480 / 650 m³/h
Cabinet air circuit: 480 / 650 m³/hMounting Wall mounted (with frame) Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
975 x 517 x 205 mm Weight 70 kg Cut out dimensions 464 x 922 mm Voltage / Frequency 120 V ~ 60 Hz Current L35L35 8.2 A Starting current 14 A Max. current 9 A Nominal power L35L35 979 W Max. power 1078 W Fuse 13 A (T) Connection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Certification (UK) UKCA declaration Video Peltier cabinet cooling units Stainless steel AISI 316 (V4A) housing part no. 68053154 Box dimension 1060 x 612 x 260 mm Gross weight 79.5 kg Taric code 84158300
