Features
- Exceptional air flow performance with outstanding value for money
- Energy-efficient product lineup
- Suitable for indoor and outdoor (black models) applications
- Models with IP 55 protection available
- Tool-free mounting, easy and quick replacement of the filter media
- Pair our FDA-approved, UL-certified protection hoods with SOLIVENT PRO filter fans for cleanroom and food-grade applications
- Customised colour options upon request
For complimentary exhaust filters, please click HERE
Order Number 4711022001 Brand Name SOLIVENT PRO Colour RAL 7035 Housing Material PC plastic / RAL 7035 IP protection class to EN 60 529 IP 54 UL Typ (UL 50E) 12 Approvals CE, cURus, cULus UL File Number E498756 Accessories Hose-proof protection hood FC 4000 000Hose-proof protection hood FC 4000 000 FDAThermostat 301050 Spare Parts Spare part filter #02 for SF 4711 Air flow unimpeded IP 54 21 / 23 m³/hr Air flow with exhaust filter IP 54 12 / 13 m³/hr Air flow with 2 exhaust filters IP 54 17 / 18 m³/hr Operating Temperature Range -10°C - 60°C Storage temperature range -40°C - 70°C Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
115.5 x 115.5 x 80.6 (11.6+69) mm Weight 0.3 kg Cut out dimensions 92 x 92 mm Voltage / Frequency 230 V ~ 50/60 Hz Rated current 0.24 / 0.25 A Power consumption 3.6 / 3.9 W Noise level 32 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4711022003 54 12 / 3R RAL 9005 B 21 / 23 m³/hr 12 / 13 m³/hr 471102R2001 54 12 / 3R RAL 7035 S 19 / 20 m³/hr 471102R2003 54 12 / 3R RAL 9005 S 19 / 20 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Air flow unimpeded IP 54 21 / 23 m³/hr Air flow with exhaust filter IP 54 12 / 13 m³/hr Air flow with 2 exhaust filters IP 54 17 / 18 m³/hr Operating Temperature Range -40°C - 60°C Storage temperature range -40°C - 70°C Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
115.5 x 115.5 x 80.6 (11.6+69) mm Weight 0.3 kg Cut out dimensions 92 x 92 mm Voltage / Frequency 230 V ~ 50/60 Hz Rated current 0.24 / 0.25 A Power consumption 3.6 / 3.9 W Noise level 32 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO No Order Information
Order Number 4711122001 Brand Name SOLIVENT PRO Colour RAL 7035 Housing Material PC plastic / RAL 7035 IP protection class to EN 60 529 IP 54 UL Typ (UL 50E) 12 Approvals CE, cURus, cULus UL File Number E498756 Accessories Hose-proof protection hood FC 4000 000Hose-proof protection hood FC 4000 000 FDAThermostat 301050 Spare Parts Spare part filter #02 for SF 4711 Air flow unimpeded IP 54 21 / 23 m³/hr Air flow with exhaust filter IP 54 12 / 13 m³/hr Air flow with 2 exhaust filters IP 54 17 / 18 m³/hr Operating Temperature Range -10°C - 60°C Storage temperature range -40°C - 70°C Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
115.5 x 115.5 x 80.6 (11.6+69) mm Weight 0.3 kg Cut out dimensions 92 x 92 mm Voltage / Frequency 120 V ~ 50/60 Hz Rated current 0.22 / 0.21 A Power consumption 3.2 / 3.3 W Noise level 32 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4711122003 54 12 / 3R RAL 9005 B 21 / 23 m³/hr 12 / 13 m³/hr 471112R2001 54 12 / 3R RAL 7035 S 19 / 20 m³/hr 471112R2003 54 12 / 3R RAL 9005 S 19 / 20 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Air flow unimpeded IP 54 24 / 26 m³/hr Air flow with exhaust filter IP 54 14 / 15 m³/hr Air flow with 2 exhaust filters IP 54 17 / 18 m³/hr Operating Temperature Range -40°C - 60°C Storage temperature range -40°C - 70°C Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
115.5 x 115.5 x 80.6 (11.6+69) mm Weight 0.3 kg Cut out dimensions 92 x 92 mm Voltage / Frequency 120 V ~ 50/60 Hz Rated current 0.22 / 0.21 A Power consumption 3.2 / 3.3 W Noise level 32 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO No Order Information
Order Number 4711322001 Brand Name SOLIVENT PRO Colour RAL 7035 Housing Material PC plastic / RAL 7035 IP protection class to EN 60 529 IP 54 UL Typ (UL 50E) 12 Approvals CE, cURus, cULus UL File Number E498756 Accessories Hose-proof protection hood FC 4000 000Hose-proof protection hood FC 4000 000 FDA Spare Parts Spare part filter #02 for SF 4711 Air flow unimpeded IP 54 21 m³/hr Air flow with exhaust filter IP 54 15 m³/hr Air flow with 2 exhaust filters IP 54 16 m³/hr Operating Temperature Range -10℃ - 60℃ Storage temperature range -40℃ - 70℃ Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
115.5 x 115.5 x 80.6 (11.6+69) mm Cut out dimensions 92 x 92 mm Voltage / Frequency 24 V DC Rated current 0.6 A Power consumption 14.4 W Noise level 56 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4711322003 54 12 / 3R RAL 9005 B 21 m³/hr 15 m³/hr 471132R2001 54 12 / 3R RAL 7035 S 19 m³/hr 471132R2003 54 12 / 3R RAL 9005 S 19 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Order Number 4711322003 Brand Name SOLIVENT PRO Colour RAL 9005 Housing Material PC plastic / RAL 7035 IP protection class to EN 60 529 IP 54 UL Typ (UL 50E) 12 Approvals CE, cURus, cULus UL File Number E498756 Accessories Hose-proof protection hood FC 4000 000Hose-proof protection hood FC 4000 000 FDA Spare Parts Spare part filter #02 for SF 4711 Air flow unimpeded IP 54 21 m³/hr Air flow with exhaust filter IP 54 15 m³/hr Air flow with 2 exhaust filters IP 54 16 m³/hr Operating Temperature Range -10℃ - 60℃ Storage temperature range -40℃ - 70℃ Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
115.5 x 115.5 x 80.6 (11.6+69) mm Cut out dimensions 92 x 92 mm Voltage / Frequency 24 V DC Rated current 0.6 A Power consumption 14.4 W Noise level 56 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4711322003 54 12 / 3R RAL 9005 B 21 m³/hr 15 m³/hr 471132R2001 54 12 / 3R RAL 7035 S 19 m³/hr 471132R2003 54 12 / 3R RAL 9005 S 19 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
