Features
- modern industrial design
- guarantees a constant cabinet temperature
- energy saving up to 76% possible
- significantly less refrigerant resulting in a reduction of the CO₂ equivalence
- high operational reliability
- RS 485 communication interface included
Quick Links
Cooling capacity L35L35 (EN14511-3) 2550 W Cooling capacity L35L50 (EN14511-3) 2160 W Compressor type BLDC Rotary Piston Refrigerant / GWP R134a / 1430 Refrigerant charge 368 g / 13 oz. High / low Pressure 30 / 6 bar
435 / 88 psigOperating Temperature Range 10°C - 60°C UL temperature range 10°C - 60°C Air flow volume (system / unimpeded) Ambient air circuit: 680 / 1200 m³/h
Cabinet air circuit: 500 / 850 m³/hMounting Wall mounted / Recessed Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
1,350 x 395 x 210 (55+155) mm Weight 45 kg Cut out dimensions 1315 x 365mm Voltage / Frequency 115-250 V ~ 50/60 Hz UL Voltage / Frequency 120-230V 60Hz Current L35L35 9.2 A / 4.6 A Starting current 16 A / 8 A Max. current 12.6 A / 6.3 A Nominal power L35L35 1.02 kW Max. power 1.42 kW Fuse 24 A (T) / 12 A (T) Short-circuit current rating 5 kA Rated current compressor 1.83 A Full load current fans 1.4 A Connection 5 pole terminal for signals
4 pole terminal for power
3 pole terminal block for RS 485 ModbusDatasheet Generate PDF Instruction manual Generate PDF CAD files STP2D PDF Mounting template DWG Certification EC declaration Certification (UK) UKCA declaration Box dimensions 1442 x 495 x 242 mm Gross weight 50.5 Kg Taric code 84158200
