Features
- der nanobeschichtete hydrophobe Kondensator erlaubt einen filterlosen Betrieb
- wartungsfrei
- für aggresive Umgebungen verschiedene Filteroptionen erhältlich
- einstellbare elektronische Steuerung mit Display
- Wandanbau oder Halbeinbau
Order Number 43050081 Brand Name COMPACT INDOOR Color RAL 7035 Housing Material Mild steel, powder coated Ingress protection TYPE 12 Sk Hinweis Customer: Spinner Approvals CE, cURus, cULus Accessories Filter holder 4305/08/09/10Fibre filter media 4305/08/09/10Washable aluminium filter 4305/08/09/10 Cooling capacity 95F/95F 2120 BTU Cooling capacity 95F/122F 1500 BTU Compressor type Reciprocating compressor Refrigerant / GWP R134a / 1430 Refrigerant charge 127 g / 4.5 oz High / low pressure 23.3 / 5.3 bar
338 / 77 psigOperating temperature range 68°F - 131°F Air volume flow (system / unimpeded) Ambient air circuit: 256 / 324 cfm
Cabinet air circuit: 118 / 147 cfmMounting Recessed Dimension H x W x D A = Height | B = Width | C = Depth
28 x 14.6 x 10.2 inch Weight 61 lbs. Cut out dimensions 12.4 x 25.7 inch Voltage / Frequency 230 V ~ 50/60 Hz UL Voltage / Frequency 230 V ~ 60 Hz Current 95F95F 2.1 A Starting current 9.8 A Max. current 2.5 A Nominal power 95F95F 370 W @ 50 Hz
400 W @ 60 HzMax. power 510 W Fuse 6 A (T) Short-circuit current rating 5 kA Connection Connection terminal block Datasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DWG Certification EC declaration Zertifizierung (UK) UKCA declaration Video Installation of SoliTherm ComPact enclosure air conditioners Stainless steel housing part no. 43050026 Taric code 84158200
