Order Number 4220A4000 Color RAL 7035 Housing Material ABS Plastic Ingress protection IP 54, Type 12, 3R Optional # 4220A4003 black Approvals CE, cULus, CSA Operating temperature range 14°F - +131°F Air volume flow unimpeded 27 cfm / 29 cfm Static pressure 0.22 inH2O @ 50Hz
0.25 inH2O @ 60HzDimension H x W x D A = Height | B = Width | C = Depth
5.9 x 5.9 x 2.9 inch Weight 1.76 lbs Cut out dimensions 4.9 x 4.9 (+0.06) inch Voltage / Frequency 230 V ~ 50/60 Hz Rated current 0.11 A / 0.10 A Power consumption 18 W / 17 W Degree of separation 85% - DIN 24185 Wall thickness 0.04 - 0.08 in. Filter class G3 according to EN 779 Installation Elastic clips or by 4 self-threading screws Noise level 48 dB(A) @ 50 Hz
54 dB(A) @ 60 HzDatasheet Generate PDF CAD files 3D - PDFSTEP Certification EC declaration Zertifizierung (UK) UKCA declaration With NEMA 3R protection part no. 4220A4030 Taric code 84145915 GTIN (EAN) 5350604100305
