Features
- Außergewöhnliche Luftstromleistung mit hervorragendem Preis-Leistungsverhältnis
- Energieeffiziente Produktpalette
- Geeignet für Indoor und Outdoor (schwarze Modelle) Anwendungen
- Modelle mit Schutzart IP 55 erhältlich
- Werkzeuglose Montage, einfacher und schneller Filterwechsel
- Kombinieren Sie unsere FDA-zugelassenen, UL-zertifizierten Strahlwasserhauben mit SOLIVENT PRO-Filterlüftern für Reinraum- und Lebensmittelanwendungen
- Individuelle Farboptionen auf Anfrage
Für ergänzende Austrittsfilter bitte hier DRÜCKEN
Order Number 4714833201 Brand Name SOLIVENT PRO Color RAL 7035 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12 Approvals CE, cURus, cULus UL File Number E498756 Accessories FC 4000 100FC 4000 100 FDAThermostat 301050 Spare Parts Ersatzfilter #02 für SF 4714 Air flow unimpeded IP 54 40.3 CFM Air flow with exhaust filter IP 54 28.0 CFM Air flow with 2 exhaust filters IP 54 32.8 CFM Operating temperature range 14˚F - 131˚F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Weight 1.32 lbs. Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 100-240 VAC ~ 50/ 60 Hz Rated current 0.18 / 0.18 A Power consumption 15 / 15 W Noise level 51.5 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4714833203 54 12 / 3R RAL 9005 B 68 m³/hr 48 m³/hr 471483R3201 54 12 / 3R RAL 7035 S 63 m³/hr 471483R3203 54 12 / 3R RAL 9005 S 63 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Order Number 4714833203 Brand Name SOLIVENT PRO Color RAL 9005 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12 Approvals CE, cURus, cULus UL File Number E498756 Accessories FC 4000 100FC 4000 100 FDA Spare Parts Ersatzfilter #02 für SF 4714 Air flow unimpeded IP 54 40.3 CFM Air flow with exhaust filter IP 54 28.0 CFM Air flow with 2 exhaust filters IP 54 32.8 CFM Operating temperature range 14˚F - 131˚F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Weight 1.32 lbs. Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 100-240 VAC ~ 50/ 60 Hz Rated current 0.18 / 0.18 A Power consumption 15 / 15 W Noise level 51.5 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4714833203 54 12 / 3R RAL 9005 B 68 m³/hr 48 m³/hr 471483R3201 54 12 / 3R RAL 7035 S 63 m³/hr 471483R3203 54 12 / 3R RAL 9005 S 63 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Order Number 4714022201 Brand Name SOLIVENT PRO Color RAL 7035 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12 Note IP 55 with filter O3 (see manual) Approvals CE, cURus, cULus UL File Number E498756 Accessories FC 4000 100FC 4000 100 FDAThermostat 301050 Spare Parts Ersatzfilter #02 für SF 4714Ersatzfilter #03 für SF 4714 Air flow unimpeded IP 54 25.8 / 27.7 CFM Air flow with exhaust filter IP 54 18 / 20.2 CFM Operating temperature range 14˚F - 131˚F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Weight 1.98 lbs. Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 230 V ~ 50/60 Hz Rated current 0.17 / 0.17 A Power consumption 20 / 17 W Noise level 46 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4714022203 54 12 / 3R RAL 9005 B 44 / 47 m³/hr 31 / 34 m³/hr 4714023201 55 12 / 3R RAL 7035 B 30 / 36 m³/hr 23 / 27 m³/hr 4714023203 55 12 / 3R RAL 9005 B 30 / 36 m³/hr 23 / 27 m³/hr 471402R2201 54 12 / 3R RAL 7035 S 46 / 51 m³/hr 471402R2203 54 12 / 3R RAL 9005 S 46 / 51 m³/hr 471402R3201 55 12 / 3R RAL 7035 S 41 / 44 m³/hr 471402R3203 55 12 / 3R RAL 9005 S 41 / 44 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Order Number 4714022203 Brand Name SOLIVENT PRO Color RAL 9005 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12, 3R Note IP 55 with filter O3 (see manual) Approvals CE, cURus, cULus UL File Number E498756 Air flow unimpeded IP 54 30.6 / 35.3 CFM Air flow with exhaust filter IP 54 18 / 20.2 CFM Operating temperature range -40°F - 131°F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Weight 1.98 lbs. Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 230V ~ 50/60 Hz Rated current 0.17 / 0.17 A Power consumption 17 / 20 W Noise level 46 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO
Order Number 4714122201 Brand Name SOLIVENT PRO Color RAL 7035 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12 Note IP 55 with filter O3 (see manual) Approvals CE, cURus, cULus UL File Number E498756 Accessories FC 4000 100FC 4000 100 FDAThermostat 301050 Spare Parts Ersatzfilter #02 für SF 4714Ersatzfilter #03 für SF 4714 Air flow unimpeded IP 54 25.8 / 27.7 CFM Air flow with exhaust filter IP 54 18 / 20.2 CFM Operating temperature range 14˚F - 131˚F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 120 V ~ 50/60 Hz Rated current 0.26 / 0.26 A Power consumption 21 / 18 W Noise level 45 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4714122203 54 12 / 3R RAL 9005 B 44 / 47 m³/hr 31 / 34 m³/hr 4714123201 55 12 / 3R RAL 7035 B 30 / 36 m³/hr 23 / 27 m³/hr 4714123203 55 12 / 3R RAL 9005 B 30 / 36 m³/hr 23 / 27 m³/hr 471412R2201 54 12 / 3R RAL 7035 S 46 / 51 m³/hr 471412R2203 54 12 / 3R RAL 9005 S 46 / 51 m³/hr 471412R3201 55 12 / 3R RAL 7035 S 41 / 44 m³/hr 471412R3203 55 12 / 3R RAL 9005 S 41 / 44 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Order Number 4714122203 Brand Name SOLIVENT PRO Color RAL 9005 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12, 3R Note IP 55 with filter O3 (see manual) Approvals CE, cURus, cULus UL File Number E498756 Air flow unimpeded IP 54 25.8 / 27.7 CFM Air flow with exhaust filter IP 54 18 / 20.2 CFM Operating temperature range -40°F - 131°F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 120 V ~ 50/60 Hz Rated current 0.26 / 0.26 A Power consumption 21 / 18 W Noise level 45 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO
Order Number 4714322201 Brand Name SOLIVENT PRO Color RAL 7035 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12 Note IP 55 with filter O3 (see manual) Approvals CE, cURus, cULus UL File Number E498756 Accessories FC 4000 100FC 4000 100 FDA Spare Parts Ersatzfilter #02 für SF 4714Ersatzfilter #03 für SF 4714 Air flow unimpeded IP 54 34.6 CFM Air flow with exhaust filter IP 54 24.5 CFM Operating temperature range 14˚F - 131˚F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Weight 1.32 lbs. Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 24 V DC Rated current 0.21 A Power consumption 5 W Noise level 44.5 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4714322203 54 12 / 3R RAL 9005 B 59 m³/hr 42 m³/hr 4714323201 55 12 / 3R RAL 7035 B 39 m³/hr 28 m³/hr 4714323203 55 12 / 3R RAL 9005 B 39 m³/hr 28 m³/hr 471432R2201 54 12 / 3R RAL 7035 S 56 m³/hr 471432R2203 54 12 / 3R RAL 9005 S 56 m³/hr 471432R3201 55 12 / 3R RAL 7035 S 47 m³/hr 471432R3203 55 12 / 3R RAL 9005 S 47 m³/hr 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Order Number 4714322203 Brand Name SOLIVENT PRO Color RAL 9005 Housing Material PC plastic / RAL 7035 Ingress protection to EN 60 529 IP 54 UL Typ (UL 50E) 12, 3R Note IP 55 with filter O3 (see manual) Approvals CE, cURus, cULus UL File Number E498756 Air flow unimpeded IP 54 34.6 CFM Air flow with exhaust filter IP 54 24.5 CFM Operating temperature range -40°F - 131°F Storage temperature range -40˚F - 158˚F Mounting Wall mounted Dimension H x W x D A = Height | B = Width | C = Depth
147.5 x 147.5 x 82.6 (11.6+71) mm Weight 1.32 lbs. Cut out dimensions 4.88 x 4.88 inch Voltage / Frequency 24 V DC Rated current 0.21 A Power consumption 5 W Noise level 44.5 dB(A) Fuse 1 A (T) Datasheet Generate PDF Instructions User manual SOLIVENT PRO
