Features
- bestens für Edelstahlschränke und Bedienpulte geeignet
- für Indoor- und Outdooranwendungen
- wartungsfrei
- können in fast jeder Lage montiert werden
(Hinweis: abhängig von der Installation ist das Kondensatmanagement evtl. anzupassen)
Order Number 6805303 Brand Name SOLITHERM PELTIER Housing Material Stainless steel AISI 304 (V2A) Ingress protection IP 66 / UL Type 12, 4, 4X Note The torque for the mounting nuts should be 4.5 Nm. Approvals CE, cURus Accessories Condensate Kit 6805 Cooling capacity 95F/95F 2730 BTU Operating temperature range -4°F - 149°F UL temperature range -20°C - 65°C Air volume flow (system / unimpeded) Ambient air circuit: 280 / 383 cfm
Cabinet air circuit: 280 / 383 cfmMounting recessed Dimension H x W x D A = Height | B = Width | C = Depth
972 x 514 x 211 (136,5+74,5) mm Weight 146 lbs. Cut out dimensions 18.3 x 36.3 inch Voltage / Frequency 120 V, 230 V Current 95F95F 8.2 A @ 120 V
4.3 A @ 230 VStarting current 14 A @ 120 V
8 A @ 230 VMax. current 9 A @ 120 V
4.7 A @ 230 VNominal power 95F95F 979 W Max. power 1078 W Fuse 13 A (T) @ 120 V
7 A (T) @ 230 VConnection 4 pole power connector
5 pole connector for signalsDatasheet Generate PDF Instruction manual Generate PDF CAD files STEP Mounting template DXF Certification EC declaration Zertifizierung (UK) UKCA declaration Video Peltier enclosure cooling units Stainless steel AISI 316 (V4A) housing part no. 68053034 Verpackungsmaße 1060 x 612 x 260 mm Bruttogewicht 75.5 kg Taric code 84158300
